The A-Designs Audio EM-EQ2 is the answer for those who want the stellar sound of a Pultec equalizer plus the added benefit of modern performance and reliability. The EM-EQ2 faithfully preserves the EQ section design, control layout, and wonderfully smooth musicality of the original Pultec. It also has the same frequency settings and inductors that made the Pultec a must-have for accurately capturing and shaping the sound spectrum, especially the bottom end. The high band is attenuated at 5k, 10k, 20kHz; bandwidth and boost can be varied mid to high band at 3k, 4k, 5k, 6k, 10k, 12k, 16kHz; and, of course, the low band can be boosted and/or attenuated at 20Hz, 30Hz, 60Hz, or 100Hz. Boost and attenuation can be adjusted from 0dB to ±10dB.
Eminently suited for tracking, mixing, or mastering, the two-channel EM-EQ2 is housed in a rugged, metal 2U chassis. It shares the same custom-milled faceplate, brushed-aluminum control knobs, big jewel power indicator lamp, and heavy-duty Carling toggle switch as the A Designs Hammer (which compliments the EM-EQ2 perfectly). Additional features include a proprietary nickel-core Cinemag output transformer, Wima capacitors, and true hard bypass. Instead of using common off-the-shelf chokes, A-Designs Audio employs a Cinemag custom wound tapped inductor.
SPECIFICATIONS
- Dual mono, three-band band, Pultec-style EQ.
- Faithfully preserves the EQ section design, controls, and musicality of the Pultec EQP-1.
- Eminently suited for tracking, mixing, or mastering.
- Same frequency settings and inductors as original Pultec make it a must-have for capturing bottom end.
- Fully balanced, noise-free performance and modern impedance specs.
- Quick and easy studio integration.
- Wima capacitors.
- True hard bypass.
- A-Designs proprietary, custom-wound tapped Inductor.
- A-Designs proprietary nickel core output transformer.
- Rugged 2U metal housing with custom-milled faceplate and control knobs.
- Big jewel power indicator lamp with heavy duty Carling power toggle switch.
- Boost: 0dB to +10dB
- Attenuate: 0dB to –10dB
- Attenuate high band: 5k, 10k, 20kHz.
- Vary bandwidth/boost mid to high band: 3k, 4k, 5k, 6k, 10k, 12k, 16kHz Boost/attenuate low band: at 20Hz, 30Hz, 60Hz, or 100Hz
