Compact design – giant tone.
The RNDI-M brings the stunning tone & clarity of its award-winning counterparts to an even more compact and pedalboard-friendly format, with the exact same custom Rupert Neve Designs transformers and discrete FET input stage as the best-selling RNDI, RNDI-S and RNDI-8.
By streamlining its feature set and housing the electronics in a rugged & more compact chassis, the RNDI-M fits neatly into any space and will allow even more musicians and engineers to tap into the uncompromised sonic power & vibrancy of a Rupert Neve Designs DI.
Compact design – giant tone.
The RNDI-M brings the stunning tone & clarity of its award-winning counterparts to an even more compact and pedalboard-friendly format, with the exact same custom Rupert Neve Designs transformers and discrete FET input stage as the best-selling RNDI, RNDI-S and RNDI-8.
By streamlining its feature set and housing the electronics in a rugged & more compact chassis, the RNDI-M fits neatly into any space and will allow even more musicians and engineers to tap into the uncompromised sonic power & vibrancy of a Rupert Neve Designs DI.
Specifications:
NOISE (22 Hz - 22 kHz, Un-weighted)
Better than -110 dBV
INPUT IMPEDANCE
Instrument Input: 2.2 Megohm
OUTPUT IMPEDANCE
Less than 40 Ohms
MAXIMUM INPUT LEVEL
Instrument Input: +20.5 (8.2 Volts RMS)
MAXIMUM OUTPUT LEVEL
+11.5 dBu Typical
FREQUENCY RESPONSE
+/- 0.25 dB from 28 Hz – 60 kHz
+/- 1 dB from 14 Hz – 90 kHz
-3 dBu below 5 Hz
TOTAL HARMONIC DISTORTION + NOISE
@ 1 kHz, +20 dBu input level: 0.25% Typical (2nd and 3rd Harmonic)
@ 1 kHz, -20 dBu input level: 0.015% Typical (2nd and 3rd Harmonic)
@ 20 Hz, -20 dBu input level: 0.75% Typical (2nd and 3rd Harmonic)
POWER REQUIREMENTS
4.5mA @ +48VDC
WEIGHTS & DIMENSIONS
Product Dimensions (W x D x H): 3.25” (8.25 cm) x 4.75” (12.1 cm) x 1.75” (4.45 cm)
Shipping Dimensions (L x W x H): 4.125” (10.5 cm) x 5.125” (13 cm) x 2” (5.1 cm)
Shipping Weight: 1.25 lbs. (0.57 kg)
