After tracking down the engineers who designed and built the original legendary RCA 44 ribbon microphones, AEA acquired ribbon material, made the tooling, and custom machined all the parts necessary to build the original RCA 44 B/BX design to its original specifications, in their own AEA R44CE design. Built just like they were in the 1930s, the R44CE from AEA flies in the face of every trend in modern ribbon microphone design, and to glorious results. After years of painstaking work, AEA has again begun production of the most important ribbon mic design of all time.
Specifications
- Operating Principle: Pressure gradient microphone
- Directional Pattern: Bidirectional (Figure-of-8)
- Frequency Range: 20 Hz to 15 kHz
- Maximum SPL: 165+ dBSPL (1% third harmonic > 1 kHz)
- Output Sensitivity: 2.25 mV/Pa (-53 dBV) into unloaded circuit
- Output Impedance: 270 Ω nominal
- Recommended Load Impedance: 1.2 kΩ or greater
- Powering: Not required or recommended
- Polarity: Pin 2 high for positive pressure on front of microphone.
- Connector: XLR-3M wired to a 3 m captive cable
Off Axis Response:
- Polar Pattern: Native bi-directional pattern
- Horizontal: Level changes with angle, frequency response is consistent, –35 dB null at 90° / 270°
- Vertical: Level changes with angle, reduced HF response above and below 0° / 180° axis, –35 dB null at 90° / 270°
Transducer element:
- Ribbon Thickness: 1.8 μ (0.0000018 m) of pure aluminum
- Ribbon Width: 0.185” (4.7 mm)
- Ribbon Length: 2.35” (59.7 mm)
Accessories:
- Included: Custom storage / shipping case, stand adapter, manual
- Optional: Any length cable, inquire for price and delivery.
- Limited Warranty: One year parts and labor, shipping not included. Three year extended warranty if the product is registered.
- Weight with Cable: 7 lb 9 oz (3.43 kg)
- Height: 12.25” (31.1 cm)
- Width: 4.62” (11.7 cm)
- Depth: 3.25” (8.3 cm)
