The massive weight & tone of classic Rupert Neve Designs studio microphone preamps: now available for your stage.
For the last decade, the world’s leading live sound engineers have chosen Rupert Neve Designs as some of the only analog equipment to accompany their digital touring rigs. With mastering-grade 24-bit 192kHz converters and full Dante integration, the RMP-D8 finally offers the live sound world something that studios have always coveted: the sound of Rupert Neve Designs.
Classic Rupert Neve Tone
The heart of the RMP-D8 lies in the modular mic preamp cards featuring Mr. Rupert Neve’s custom transformer designs. Unlike other integrated Dante mic preamp designs that rely primarily on a single IC for gain & tone, each channel on the RMP-D8 has a fully-realized class-A microphone preamplifier feeding a custom transformer, maintaining the high standards of Rupert Neve Designs’ standalone preamplifiers.
The New Dante Standard
Dante audio networking uses standard IP networks to transmit high-quality, uncompressed audio with near-zero latency. It’s the most flexible, reliable, and easy-to-manage audio networking solution available, and provides the lowest cost of ownership by dramatically reducing cabling and labor costs. Dante is the audio networking choice of nearly all professional audio manufacturers, making it the industry standard for digital audio networking.
SPECIFICATIONS
NOISE
150 Ohm Balanced Source, AES Output, 22 Hz to 22 kHz, un-weighted, +60 dB Gain.
-91 dBFS
UNITY GAIN
-110 dBFS
FREQUENCY RESPONSE
0 dBu, Unity Gain, 96 kHz
30 Hz to 45 kHz +/- 0.2 dB
10 Hz -3 dB
INPUT IMPEDANCE
5.5K Ohm
GAIN
0 to 60 dB in 1 dB steps
HIGH PASS FILTER
-3 dB @ 80 Hz, 12 dB/Octave Slope
PAD
-10 dB
SIGNAL TO NOISE RATIO
84.4 dB
DYNAMIC RANGE
110 dB
MAXIMUM INPUT LEVEL
+25.5 dBu
UNIT DIMENSIONS & WEIGHT
2RU: 19” (W) x 3.5” (H) x 12.25” (D)
48.25 cm (W) x 8.9 cm (H) x 31.1 cm (D)
13.5 lbs. (6.1 kg)
UNIT WEIGHT
SHIPPING DIMENSIONS & WEIGHT
22” (W) x 18” (D) x 9” (H)
55.9 cm (W) x 45.7 cm (D) x 22.9 cm (H)
17.6 lbs. (8 kg)
SHIPPING WEIGHT
17.6 lbs. (8 kg)
POWER CORD TYPE
IEC Standard 3 Pin 18AWG Latching Type
