Transform your tone.
For over six decades, audio transformers have been the bedrock of Mr. Rupert Neve’s audio circuit design philosophy – and Rupert Neve Designs’ bespoke transformers are an integral part of virtually every RND product.
Packed with these transformers, the MBT provides an incredible array of flavorful options designed to sweeten, enhance, drive, widen, and utterly transform source material, making it the ultimate tool for musical coloration.
Note: All measurements typical; All measurements recorded using 25ft. XLR output cables with Balanced ZSOURCE = 40 ohm
Input Impedance: 10 kilohm
No Features Engaged
Noise (22 Hz - 22kHz): Better than -95 dBu
THD+N (0 dBu @ 1kHz): Better than 0.004%
THD+N (+20 dBu @ 1 kHz): Better than 0.002%
Maximum Input Level: +25.5 dBu
Crosstalk @ 1 kHz: Better than -95 dB
Frequency Response:
<5 Hz - 30 kHz: +/- 0.1 dB
<5 Hz - 60 kHz: +/- 0.25 dB
<5 Hz - 180 kHz: -3 dB
HPF Engaged
Noise (22 Hz - 22 kHz): Better than -95 dBu
THD+N (+20 dBu @ 1 kHz): Better than 0.002%
Equalizer Engaged
Noise (22 Hz - 22 kHz): Better than -93dBu
THD+N (+20 dBu @ 1 kHz): Better than 0.002%
Compressor Engaged
Noise (22 Hz - 22 kHz): Better than -92dBu
THD+N (+20 dBu @ 1 kHz): Better than 0.002%
Width Engaged
Noise (22 Hz - 22 kHz): Better than -88dBu
THD+N (+20 dBu @ 1 kHz): Better than 0.002%
SILK Engaged
Noise (22 Hz - 22 kHz): Better than -95dBu
THD+N (+20 dBu @ 1 kHz): Better than 0.003%
WEIGHTS & DIMENSIONS
Product Dimensions (W x D x H): 19” (48.3 cm) x 10.125” (25.7 cm) x 3.5” (8.9 cm)
Shipping Dimensions (L x W x H): 22” (55.9 cm) x 18” (45.7 cm) x 8.7” (22.1 cm)
Shipping Weight: 17 lbs. (7.7 kg)
