BD960

Practical And Economical Obscenity Protection

Whether you are a station servicing a smaller market or you are broadcasting a shock jock in the big city, the remarkably inexpensive BD960 is ideal for safe-guarding for your live audio broadcast needs. Any station that ever plans a live call-in or even slightly risky in-studio guest will benefit from having a BD960 delay unit in its protective arsenal.

You're on the air, and someone has just opened his or her big mouth a little too wide. Don't Panic!

Just hit the Delete button, and the obscene caller or out-of control studio guest never reaches the air. The Delete function also closes a relay contact. With an easily built relay box, this can automatically start a six (or three or twelve) second cart - a short program promo, a station ID, a funny "zapper," anything you want. When the delay period "plays out," your delay switches you back "almost live" on the air with full delay protection restored. The whole operation takes just one button. What could be simpler?

What could be simpler, indeed!

How about "no need for an easily built relay box or filler cart"? With the BD960, you need no relay, no filler cart - because filler playback is built into the unit! The BD960 AutoFill™ Broadcast Delay has a built-in memory to store material to use to fill those embarrassing silences while the delay period is regained. Since the memory is non-volatile, you don't have to worry about losing it in a power failure; since it's fully electronic, you don't have to worry about loss of quality as it gets played and played and played. And, perhaps best of all, since it doesn't add to the cost of the unit, you don't have to justify paying extra for the feature!

Features

Some choices you don't have to make...

Previous BD900-series models required you to specify mono or stereo and the delay length at the time of ordering. But you don't have to make these choices with the BD960. ALL units are stereo, ALL have a maximum delay of eight seconds, adjustable to any value up to the maximum. And with the low cost of the BD960, you don't need to choose whether to run unprotected on incidental programs, remotes, or on other occasions. Sure, if you're a heavy talk station, you will probably want our world-standard BD500 delay with its patented "catch up" feature and ability to unobtrusively build up delay with no program interruption. But any station that ever plans a live call- in or even slightly risky instudio guest will benefit from having a BD960 delay unit in its protective arsenal.

One Button Delete

Full Stereo

8 Second, Fully Adjustable Delay

Autofill Built-In Filler Playback

Non-Volatile Digital Memory

Industry Standard XLR-Type I/O

Compact 1-U Design

RS-232 Serial Interface

You can't say that on the radio...

But people who know that sometimes slip, and many enjoy testing limits. Recent changes and decisions at the FCC have made it more risky than ever to be risqué, and libel lawsuits and penalties in the U.S. and other countries can be more costly than FCC fines. With its spectacular audio specifications, the BD960 lets you control these risks with maximum convenience for you and transparency for your listeners.

Specifications

Input / Output

Analog Input

Audio Input Connectors                   2 XLR female balanced line  Input

Impedance                                         10K ohms bridging

Input Level                                         -6 dBm to +25 dBm, adjustable +/- 10dB

Analog Output



Audio Output Connectors                2 XLR male balanced line

Output Impedance                            Less than 50 ohms, balanced, for driving 600 ohm                                                                  load

Output Drive                                      Output amplifier clipping level > +25dBm

Signal

A/D and Digital Signal Path Characteristics

A/D/A Conversion                               24-bit

Dynamic Range                                 >100dB

Sampling Rate                                    48kHz

Frequency Response                        10Hz - 22kHz +/- 1dB

Crosstalk                                            <-95dB

THD/N                                               <0.008%

Recorded Signal ("Filler Cart") Specification

Length                                                  Up to 8 seconds stereo

Dynamic Range                                 >100dB

Sampling Rate                                    24kHz

Frequency Response                          10Hz - 11kHz +/- 1dB

THD/N                                               <0.005%

Controls & Indicators

Operating Controls and Indicators

Controls                                             POWER, LEVEL Up/Down, BYPASS, DELETE, RECORD

Indicators                                           POWER, Dual 8-LED LEVEL bargraphs,                                                                                 BYPASSED, DELETE, RECORD, DELAY

Remote Control Connectors and Signals

Delete Delay                                      2 N/O relay contacts that close during DELETE

Remote Jack                                       Allows external contact closure to ground to cause                                                                DELETE and BYPASS

 SRS232                                              Allows simple remote control from a PC or other                                                                    computer


Physical

Width                                                  Standard 19" (48.26cm) rack

Height                                                 Standard 1u (1 3/4" / 4.44 cm) rack mount

Depth Behind Panel                          10.5"/26.67cm excluding connectors

Temperature Range                         40-120 deg F (5-49 C)

Power Requirement                         Less than 25 watts, 100-240 volts universal power                                                                 supply
