SPL Vitalizer MK3-T

SPL Vitalizer MK3-T

Regular price R 27,960.00 ZAR
Regular price Sale price R 27,960.00 ZAR
Sale Sold out

The patented Vitalizer circuitry makes the Vitalizer Mk3-T an unsurpassed sound designer.
Whether live or in the studio, audio productions sound more alive, have more details, more transparency, a higher perceived loudness and, if required, an overwhelming bass fundament.

The Vitalizer Mk3-T not only swaps the classic, golden robe of the previous model for the new, black design of the SPL Studio Series – the higher internal audio voltage of +/-18 V elevates this third generation SPL classic to greater sonic results and impresses with an even better and more detailed sound experience.

OVL

The OVL LED indicates a potential overload of the input stages as well as internal overloads. The OVL LED lights up 3 dB before an overload. This ensures that the Vitalizer always delivers the perfect sound.


Bass Sound

The Bass Sound control can be used to adjust between two bass sound colors.

Soft:
Moving the Bass Sound control from the center position (0) to the left makes bass sounds soft and warm, referred to as Soft.

Tight:
If the Bass Sound control is moved from the center position (0) to the right, this makes bass sounds dry and percussive, referred to as Tight.

Specifications:

Analog inputs & outputs; XLR & TRS Jack (balanced)

Input impedance: 22
Output impedance: 75 Ω
Maximum input level: 22.5 dBu
Common Mode Rejection Ratio (CMRR): 86 dB
Frequency range (-3 dB): 10 Hz – 100 kHz
THD + N (0 dBu, 10 Hz – 22 kHz): 0.01 %
Noise (A-weighted): -99 dBu
Dynamic range: 122 dB

Internal Linear Power Supply with Shielded Toroidal Transformer

Operating voltage
for analog audio: +/- 18 V
Operating voltage for relays and LEDs: + 12 V
Tubes anode voltage: 250 V
Tubes heating voltage: 12.6 V

Mains Power Supply

Mains voltage (selectable): 230 V AC, 50; 115 V AC, 60 Hz
Fuse for 230 V: T 400 mA
Fuse for 115 V: T 800 mA
Power consumption: max. 20 W

Dimensions & Weight

W x H x D: 482 x 44 x 237 mm / 19 x 1.73 x 9.33 inch
Unit weight: 3.4 kg / 7.5 lbs
